VERTICAL CABLE 264-MCS SERIES – SPLICING LGX CASSETTES
The 264-MCS Series is a line of splicing LGX cassettes built to terminate fiber directly through fusion splicing in a standard LGX-compatible footprint. Each cassette houses one or two 12-position fusion-splice holders behind an M12/PG7 cable gland rear entry, giving installers a self-contained alternative to a standalone fiber splice tray. Available in 8, 12, 16, and 24-fiber counts with SC or LC front connectors across OM1, OM3, OM4, and singlemode UPC/APC fiber types, the 264-MCS Series covers the full range of splicing configurations most structured cabling projects call for.
KEY FEATURES
Here’s what makes the 264-MCS Series a dependable splicing LGX cassette lineup:
- Configurable Fiber Type: Available in OM1, OM3, OM4 multimode, and singlemode UPC or APC configurations.
- Multiple Fiber Counts: Choose from 8, 12, 16, or 24-fiber configurations to match project scope.
- SC or LC Connector Options: Front adapters available in SC simplex/duplex or LC simplex/duplex.
- One or Two 12-Position Splice Holders: Supports fusion splicing directly within the cassette housing.
- Rear M12/PG7 Cable Gland Entry: Accepts incoming cable with an OD of 0.08–0.25 in (2–6.5 mm) for direct splicing.
- Standard LGX Footprint: Fits standard LGX-compatible enclosures and mounting hardware.
- Zirconia Ceramic Front Adapters: Precision one-piece construction for durable, low-loss mating.
- Low Insertion Loss: SC/LC interfaces rated at 0.3 dB or lower when used with standard-compliant plugs.
- Telcordia GR-326-CORE Compliant: Meets carrier-grade connector and splice hardware standards.
- Easy Install: Comes fully pre-terminated and tested where applicable, simplifying field deployment.
APPLICATIONS
The 264-MCS Series LGX Splicing Cassette excels in field-terminated fiber installations across multimode and singlemode networks:
- Outside Plant (OSP) Terminations: Fusion splice incoming OSP fiber directly to SC or LC connectors without a separate splice tray.
- Data Centers: Terminate backbone cable runs across a range of fiber counts and types where pre-connectorized MPO trunks aren’t practical.
- Telecommunications Rooms: Provide a standardized splice-cassette termination point within MDFs and IDFs.
- Enterprise Fiber Networks: Support direct-splice multimode or singlemode connections for legacy or non-MPO fiber plant.
- Central Offices and Carrier Networks: Meet carrier-grade splice-termination requirements consistent with Telcordia and TIA guidance.
WHY CHOOSE THE 264-MCS0U12-3A90 LGX CASSETTE?
Professionals choose the 264-MCS Series for its configuration flexibility, reliable splicing performance, and universal LGX fit. Here are 5 reasons to specify it for your next project:
- Configuration Flexibility – Choose from 8 to 24-fiber counts, multimode or singlemode, and SC or LC connectors to match any project spec.
- Direct OSP Termination – Rear cable gland entry accommodates a range of cable diameters for direct fusion splicing.
- Compact, Self-Contained Design – Houses splice holders and connectors in one cassette, eliminating the need for a standalone fiber splice tray.
- Standard LGX Compatibility – Fits existing LGX enclosures and mounting hardware without modification.
- Carrier-Grade Reliability – Built to Telcordia and ANSI/TIA-568.3-D standards that installers already trust.
GETTING IT INSTALLED
Once you’ve specified your Splicing LGX cassette needed from the 264-MCS Series for your project, here’s what to keep in mind:
- Check your cable against the gland. Confirm the incoming fiber cable’s outer diameter falls between 0.08–0.25 in (2–6.5 mm) so it seats properly in the M12/PG7 gland.
- Line up your splicing crew and gear. Fusion splicing needs a trained tech and a fusion splicer on-site — worth confirming both are scheduled before the cassette shows up.
- Match your fiber count to your project. With 8, 12, 16, and 24-fiber options available, pick the count that fits your current build without over- or under-provisioning the cassette.
- Splice, test, then label. Once the splices are done, test insertion loss on each fiber and label every position right away — it saves a lot of guesswork down the road.
