VERTICAL CABLE 264-MCA SERIES – UPC MPO PRE-CONNECTORIZED LGX CASSETTE
The 264-MCA Series is a 12-fiber LGX Cassette that breaks out MPO/MTP trunk connectivity into individual LC duplex singlemode connections. Delivered fully pre-terminated and tested, this LGX Cassette pairs a Type-A MPO-12 rear interface with LC duplex front adapters optimized for singlemode UPC performance. Built to the standard LGX footprint, the 264-MCA Series works as an MPO-to-LC cassette that simplifies high-density fiber deployments by eliminating field termination while maintaining low insertion loss and carrier-grade compliance.
KEY FEATURES
Here’s what makes the 264-MCA Series an ideal LGX Cassette:
- Multiple Fiber Counts: Available in 8, 12, 16, and 24-fiber configurations to match project scope.
- Pre-Terminated and Tested: Ships ready to install, eliminating on-site termination and testing.
- SC or LC Front Adapters: Front interfaces available in SC simplex/duplex or LC duplex/quad.
- MPO-12 Type A Flanged Rear Adapter: Standard MPO/MTP trunk compatibility for a plug-and-play MPO cassette setup.
- Low-Loss or Standard-Loss Options: Choose MTP-12 pinned (US Conec) for low loss, or MPO-12 pinned (SENKO) for standard loss.
- Fiber Type Flexibility: Configurable for OM1, OM3, OM4, SM UPC, and SM APC fiber.
- Standard LGX Footprint: Fits standard LGX-compatible enclosures and mounting hardware.
- Zirconia Ceramic Front Adapters: One-piece construction for durable, low-loss mating.
- Low Assembled Insertion Loss: 0.55 dB max for the assembled cassette.
- Telcordia GR-326-CORE Compatible: Built to carrier-grade connector standards.
APPLICATIONS
The 264-MCA Series LGX Cassette excels in high-density singlemode fiber deployments:
- Data Centers: Convert MPO/MTP backbone trunks into individual duplex ports with a pre-terminated fiber optic cassette, cutting install time and testing errors.
- Telecommunications Rooms: Simplify MDF/IDF cross-connects with an MPO to LC cassette that breaks trunks out into patchable ports.
- High-Speed LAN and SAN Environments: Support switch-to-switch and storage links that rely on parallel-optic trunk cabling.
- Colocation Facilities: Standardize high-density, pre-tested fiber connectivity across multi-tenant deployments.
- Central Offices and Carrier Networks: Deliver carrier-grade singlemode connectivity from MPO trunk to duplex ports.
WHY CHOOSE THE 264-MCA SERIES LGX CASSETTE?
Professionals choose the 264-MCA Series for its plug-and-play deployment, reliable singlemode performance, and standard LGX compatibility. Here are 5 reasons to specify it for your next project:
- Faster Deployment – Fully pre-terminated and tested construction eliminates field termination, significantly cutting installation time.
- Reliable Singlemode Performance – LC UPC front adapters deliver low, consistent insertion loss for long-haul and backbone applications.
- Instant Setup – Fully pre-terminated and tested out of the box, ready to connect.
- Standard LGX Compatibility – Fits existing LGX enclosures and mounting hardware without modification.
- Carrier-Grade Reliability – Telcordia GR-326-CORE and ANSI/TIA-568.3-D compliance support demanding enterprise and carrier applications.
GETTING IT INSTALLED?
Once you’ve specified the 264-MCA Series for your project:
- Match your trunk cable. Double-check that your MPO-12 trunk uses Type-A polarity and standard loss (SENKO pinned) connectors before it arrives on site.
- Line up your LC patch cables. Singlemode UPC LC duplex patch cords complete the front-side connections—worth having these ready before install day.
- Measure your enclosure depth. Make sure the target enclosure has enough rear depth space (8 in. enclosed / 6.5 in. open) to fit the cassette comfortably.
- Connect, test, and label. Once it’s mounted and the MPO trunk is plugged in, run a quick insertion/return loss check and label all 6 LC positions so future troubleshooting is painless.
