059-485/CMXF

VERTICAL CABLE 059-485/CMXF – CAT5E DIRECT BURIAL CABLE

The 059-485/CMXF is a rugged CAT5E outdoor cable engineered for direct burial installations. Its gel-flooded core prevents moisture intrusion while the UV-resistant jacket ensures long-lasting outdoor durability.

KEY FEATURES

Here are its key features:

• Cable Type: CAT5E UTP (Unshielded Twisted Pair), 4 pairs, 8 conductors
• Bandwidth: Rated up to 350 MHz for Gigabit Ethernet, PoE, and voice/data applications
• Conductor: Solid bare annealed copper, 24 AWG (0.51 mm diameter)
• Gel Filler: Flooded core design blocks water migration along the cable
• Insulation: Polyethylene (PE), 0.04″ (0.91 mm) diameter
• Jacket Material: Linear Low-Density Polyethylene (LLDPE), UV-resistant for extended outdoor life
• Outer Diameter: 0.20″ (5.10 mm)
• Jacket Thickness (Avg/Min): 0.0236″ / 0.0212″ (0.60 mm / 0.54 mm)
• Color Coding: Standard—White/Blue, White/Orange, White/Green, White/Brown
• Rip Cord: Included for fast, clean jacket removal
• Markings: ETL Verified CMX, RoHS Compliant, TIA-568.2-D printed in sequence
• Operating Temperature: –40 °F to 167 °F (–40 °C to 75 °C)
• Voltage Rating: 60 VRMS
• Fire Rating: CMX (NEC)
• Weight: 24.3 lb (11.02 kg) per 1000 ft (304.8 m) pull box
• Color: Black

APPLICATIONS

Designed for environments exposed to moisture, this gel-filled CAT5E cable is perfect for:

• Underground Ethernet Links
• Outdoor IP Cameras and Gate Access
• Campus-to-Campus Direct Burials
• Roadside Device Networks
• Agricultural and Utility Installations

WHY CHOOSE THE 059-485/CMXF – CAT5E DIRECT BURIAL CABLE?

This cable ensures lasting performance in harsh outdoor and moisture-prone environments:

1. Flooded Core Protection: Gel filling blocks water from wicking along cable pathways.
2. Actual Copper Performance: 24 AWG solid bare copper ensures Gigabit speeds and strong PoE support.
3. Built for Outdoors: UV-rated jacket resists cracking and degradation.
4. Installer-Friendly: Rip cord and easy pair ID simplify terminations.
5. Fully Certified: ETL listed, RoHS compliant, and meets ANSI/TIA-568.2-D standards.

WHAT’S NEXT?

After choosing the 059-485/CMXF:

• Bury Direct – No conduit required for dry, in-ground installation
• Terminate and Seal – Use waterproof connectors for added protection
• Label and Test – Confirm connectivity and mark cable runs
