VERTICAL CABLE 165 SERIES – CAT6A F/UTP CMP CABLE
The 165 Series CAT6A Plenum Cable is a high-grade, shielded F/UTP cable designed for superior performance in commercial high-speed data environments. Engineered for plenum spaces, it offers safety, shielding, and signal integrity for the most demanding installations.
KEY FEATURES
Here are its key features:
- Cable Type: CAT6A F/UTP (Shielded Foil Twisted Pair)
- Conductor: 23 AWG solid bare copper
- Jacket: CMP-rated PVC jacket, fire-retardant and low-smoke
- Outer Diameter: 0.268″ (6.8 mm ± 0.3 mm)
- Weight: 48 lb (21.77 kg) per 1000 ft spool
- Packaging: 1000 ft (304.8 m) on a wooden spool
- Shield: AL/Poly tape (100% coverage) with solid tinned copper drain wire
- Pair Separator: Internal pair divider with ripcord for easy strip and termination
- Color Code: Standard 4-pair (blue/white-blue, orange/white-orange, green/white-green, brown/white-brown)
- Certifications: UL Listed, ETL Verified, RoHS Compliant
- Safety Ratings: CMP Plenum (UL 444), NEC Article 800, FT6 Rated
- Standards: ANSI/TIA 568.2-D and ISO/IEC 11801
- Compliance: Designed in the USA, TAA-Compliant imported product
APPLICATIONS
The 165 Series cable is built for fast, shielded transmission in plenum-rated environments. Ideal for:
- 10G Ethernet and Data Centers
- PoE++ (Type 1 & 2) Installations
- Broadcast and AV Signal Distribution
- Commercial and Institutional Networks
- Plenum Air Return Spaces
WHY CHOOSE THE 165 SERIES – CAT6A F/UTP CMP CABLE?
Designed for superior fire safety and signal shielding, this cable delivers performance you can trust:
- Plenum Rated: UL CMP certified for safe installation in return-air plenum spaces.
- High-Speed Ready: Supports 10 Gigabit Ethernet and other demanding applications.
- EMI Protection: Full foil shielding maintains signal integrity and minimizes interference.
- Certified Quality: UL Listed, RoHS Compliant, ETL Verified to industry standards.
- Easy Handling: Ripcord and pair separator simplify installation and reduce prep time.
WHAT’S NEXT?
After choosing your 165 Series cable:
- Select Your Color – Available in black, blue, gray, white, green, and yellow
- Match with Connectors – Compatible with CAT6A keystone jacks and shielded connectors
- Label and Test – Verify performance with network testers and mark cable runs clearly
For a more premium, similar twisted-pair cable, visit CAT6A Cables and discover top-tier solutions today!
