VERTICAL CABLE 045-TSR-6A SERIES – 6 FT SURFACE RACEWAYS (0.75 IN | 1.25 IN | 1.75 IN)

The 045-TSR-6A Series is a versatile, durable, and professional-grade surface raceway solution for managing low-voltage cabling in open environments. Available in three width sizes—0.75 inch (19.05 mm), 1.25 inch (31.75 mm), and 1.75 inch (44.45 mm)—and two finishes (Office White or Ivory), this raceway system is engineered to provide both aesthetics and reliability.

Each unit measures 6 feet (1.83 meters) in length and is crafted from UL 94 V-0 rated PVC, ensuring flame-retardant protection for residential, commercial, and industrial environments. Whether you’re installing network cabling, power wires, or A/V lines, this raceway delivers a clean and organized solution that conforms to TIA installation standards.

KEY FEATURES

Here’s a closer look at what makes the 045-TSR-6A Series a go-to surface raceway for professionals:

• Available in 3 Widths: Choose from 0.75 in. (19.05 mm), 1.25 in. (31.75 mm), or 1.75 in. (44.45 mm).
• Uniform 6 ft Length: All sizes measure 6 ft (1.83 m) for consistent surface coverage.
• Color Options: Available in Office White or Ivory to blend with most wall finishes.
• Secure, Self-Locking Cover: A tamper-resistant latch allows for quick re-entry and reliable retention.
• UL 94 V-0 PVC Construction: Flame-retardant material ensures safety and durability.
• Flexible Hinge: Prevents discoloration and cracking after repeated openings.
• Adhesive Backing: Rubber-based foam tape provides a strong bond to uneven surfaces.
• TIA-Compliant Bend Radius: Supports 1 in. (25.4 mm) minimum bend radius per ANSI/TIA-568.0 & TIA-569.
• Outlet Box Compatible: Works with junction boxes for electrical and data outlets.
• UL Listed & Packaged 20 Per Box: Meets electrical code compliance for plenum and surface runs.

*Values are approximate and may vary depending on cable type and installation conditions.

APPLICATIONS

This raceway series is well-suited for a variety of environments where cable concealment and protection are required:

• Office Cable Routing and Workstation Drops
• Structured Cabling for Schools and Retail
• AV and Security System Concealment
• Network Cabling in Commercial Buildings
• Power, Data, and Telecom in Open Spaces

WHY CHOOSE THE 045-TSR-6A SERIES RACEWAY?

When neatness, safety, and reliability are essential, the 045-TSR-6A Series provides a professional edge:

1. Tool-Free Access: Hidden latch enables easy re-entry for maintenance or upgrades.
2. Installer Friendly: Pre-taped and boxed in sets of 20 for fast bulk deployment.
3. Versatile Sizing Options: Three width variants suit light-duty to heavier multi-cable bundles.
4. Code-Compliant: UL-rated and TIA-compliant for peace of mind and professional installs.
5. Aesthetic Finish: Clean color options allow raceways to blend with existing decor.

WHAT’S NEXT?

Once you’ve selected the 045-TSR-6A Series:

• Match with Accessories – Use elbows, couplers, and junction boxes for a complete install.
• Label Runs Clearly – Maintain organization across devices and drop points.
• Expand Your Network – Route power and data together without needing in-wall conduit.
• Upgrade Cleanly – Use re-entry access to add or replace cables.
